Here are
2x QSFP28 cages for blazing-fast 100 Gigabit connectivity,
12x SFP28 cages for 25 Gigabit networking, and a
Gigabit Ethernet port. The device comes with
16 GB of RAM, decent NAND storage, and
two M.2 SATA slots for additional storage. There are four hot-swappable fans, as well as dual-redundant hot-swap power supplies. And these PSUs might look familiar if you have used our CCR1072 before: you can keep using your previous hot-swap power supplies and SFP modules.
Specifications
| Details |
| Product code |
CCR2216-1G-12XS-2XQ |
| Architecture |
ARM 64bit |
| CPU |
AL73400 |
| CPU core count |
16 |
| CPU nominal frequency |
2000 MHz |
| Dimensions |
443 x 367 x 44 mm |
| RouterOS license |
6 |
| Operating System |
RouterOS (v7 only) |
| Size of RAM |
16 GB |
| Storage size |
128 MB |
| Storage type |
NAND |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-20°C to 60°C |
| IPsec hardware acceleration |
Yes |
|
|
Powering
| Details |
| Number of AC inputs |
2 |
| AC input range |
100-240 |
| Max power consumption |
128 W |
| Max power consumption without attachments |
80 W |
| Cooling type |
4 fans |
Ethernet
| Details |
| 10/100/1000 Ethernet ports |
1 |
Fiber
| Details |
| Number of 25G SFP28 ports |
12 |
| Number of 100G QSFP28 ports |
2 |
Peripherals
| Details |
| Serial console port |
RJ45 |
| Number of M.2 slots |
2 |
Other
| Details |
| CPU temperature monitor |
Yes |
| PCB temperature monitor |
Yes |
| Voltage Monitor |
Yes |
Certification & Approvals
| Details |
| Certification |
CE, EAC, ROHS |
| IP |
20 |
